Apple iPhone 17 Pro Max

Technology
GSM / CDMA / HSPA / EVDO / LTE / 5G

2G bands
GSM 850 / 900 / 1800 / 1900
CDMA 800 / 1900

3G bands
HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
CDMA2000 1xEV-DO

4G bands
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 34, 38, 39, 40, 41, 42, 48, 53, 66 – A3526
1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 32, 34, 38, 39, 40, 41, 42, 48, 53, 66, 71 – A3257
1, 2, 3, 4, 5, 7, 8, 11, 12, 13, 14, 17, 18, 19, 20, 21, 25, 26, 28, 29, 30, 32, 34, 38, 39, 40, 41, 42, 48, 53, 66, 71 – A3525
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 34, 38, 39, 40, 41, 42, 48, 66 – A3527

5G bands
1, 2, 3, 5, 7, 8, 12, 20, 25, 26, 28, 30, 38, 40, 41, 48, 53, 66, 70, 75, 77, 78, 79 SA/NSA/Sub6 – A3526
1, 2, 3, 5, 7, 8, 12, 14, 20, 25, 26, 28, 29, 30, 38, 40, 41, 48, 53, 66, 70, 71, 75, 77, 78, 79, 258, 260, 261 SA/NSA/Sub6/mmWave – A3257
1, 2, 3, 5, 7, 8, 12, 14, 20, 25, 26, 28, 29, 30, 38, 40, 41, 48, 53, 66, 70, 71, 75, 77, 78, 79 SA/NSA/Sub6 – A3525
1, 2, 3, 5, 7, 8, 12, 20, 25, 26, 28, 30, 38, 40, 41, 48, 66, 70, 75, 77, 78, 79 SA/NSA/Sub6 – A3527

Speed
HSPA, LTE, 5G, EV-DO Rev.A 3.1 Mbps

Announced
2025, September 09

Status
Available. Released 2025, September 19

Dimensions
163.4 x 78 x 8.8 mm (6.43 x 3.07 x 0.35 in)

Weight
233 g (8.22 oz)

Build
Glass front (Ceramic Shield 2), aluminum alloy frame, aluminum alloy back/ glass back (Ceramic Shield)

SIM
Nano-SIM + eSIM + eSIM (max 2 at a time; International)
eSIM + eSIM (8 or more, max 2 at a time; USA)
Nano-SIM + Nano-SIM (China)
IP68 dust tight and water resistant (immersible up to 6m for 30 min)
Apple Pay (Visa, MasterCard, AMEX certified)

Type
LTPO Super Retina XDR OLED, 120Hz, HDR10, Dolby Vision, 1000 nits (typ), 1600 nits (HBM), 3000 nits (peak)

Size
6.9 inches, 115.6 cm2 (~90.7% screen-to-body ratio)

Resolution
1320 x 2868 pixels, 19.5:9 ratio (~460 ppi density)

Protection
Ceramic Shield 2, Mohs level 5
Anti-reflective coating

OS
iOS 26

Chipset
Apple A19 Pro (3 nm)

CPU
Hexa-core (2×4.26 GHz + 4xX.X GHz)

GPU
Apple GPU (6-core graphics)

Card slot
No

Internal
256GB 12GB RAM, 512GB 12GB RAM, 1TB 12GB RAM, 2TB 12GB RAM
NVMe

Triple
48 MP, f/1.6, 24mm (wide), 1/1.28″, 1.22µm, dual pixel PDAF, sensor-shift OIS
48 MP, f/2.8, 100mm (periscope telephoto), 1/2.55″, 0.7µm, PDAF, 3D sensor‑shift OIS, 4x optical zoom
48 MP, f/2.2, 13mm, 120˚ (ultrawide), 1/2.55″, 0.7µm, PDAF
TOF 3D LiDAR scanner (depth)

Features
Dual-LED dual-tone flash, HDR (photo/panorama)

Video
4K@24/25/30/60/100/120fps, 1080p@25/30/60/120/240fps, 10-bit HDR, Dolby Vision HDR (up to 120fps), ProRes, ProRes RAW (up to 120fps), Apple Log 2, 3D (spatial) video/audio, stereo

Single
18 MP multi-aspect, f/1.9, 20mm (ultrawide), PDAF, OIS
SL 3D, (depth/biometrics sensor)

Features
HDR, Dolby Vision HDR, 3D (spatial) audio, stereo sound rec., ProRes RAW, Apple Log 2

Video
4K@24/25/30/60fps, 1080p@25/30/60/120fps, gyro-EIS

Loudspeaker
Yes, with stereo speakers

3.5mm jack
No

WLAN
Wi-Fi 802.11 a/b/g/n/ac/6e/7, tri-band, hotspot

Bluetooth
6.0, A2DP, LE

Positioning
GPS (L1+L5), GLONASS, GALILEO, BDS, QZSS, NavIC

NFC
Yes

Radio
No

USB
USB Type-C 3.2 Gen 2, DisplayPort

Sensors
Face ID, accelerometer, gyro, proximity, compass, barometer
Ultra Wideband (UWB) support (gen2 chip)
Emergency SOS, Messages and Find My via satellite

Type
Li-Ion 4832 mAh – Nano SIM model
Li-Ion 5088 mAh – eSIM only model

Charging
Wired, PD3.2, AVS, 50% in 20 min
25W wireless MagSafe/Qi2, 50% in 30 min (15W – China)
4.5W reverse wired
